Product Details:
|
| Pressing Beam Lefting: | Numerical Control Lifting | Plate Thickness: | Gluing：10-60mm，Laser：10-40mm |
|---|---|---|---|
| Working Air Pressure: | 0.6Mpa | Overall Dimensions: | 10100x1000x2000mm |
| Total Power: | 29.5KW | Feed Speed: | Gluing：14-18-23-26m/min， Laser：≤23m/min(When The Thickness Of The Workpiece Is 18mm, The Maximum Feed Speed Is About 23m/min.) |
| Feed Speed With Corner Rounding On: | Narrow Edge Banding With Corner Rounding On：≤18m/min | Thickness Of Edge Banding Tape: | Gluing：0.4-3mm，Laser：1-3mm |
| Minimum Plate Size: | With Corner Rounding Off：120x40mm With Corner Rounding On：300x40mm |
Technical info:
l Laser system developed by Hold.
l Truly seamless edge banding effect, no need for glue. High-energy laser beam melts the functional layer on the back of the edge band and bonds it to the substrate, resulting in strong adhesion and excellent weather resistance, providing a perfect visual experience.
l Hold specializes in weather resistance technology, eliminating the need for separate "building houses", ensuring that the edge banding is not easily affected by environmental temperature and humidity.
l The laser system is ready to use when powered on, no need for heating, increasing effective working hours utilization.
l Excellent waterproof performance, resistant to high and low temperatures, environmentally friendly and non-polluting.
l Fully intelligent control system, with real-time data transmission, providing instant understanding of equipment status, and one-click production report generation.
l In addition to laser edge banding, PUR non-cleaning glue pot + dual glue machine can also be selected.
l Patented laser system technology, perfectly compatible with ABS, PP, acrylic, and laser edge bands with functional layers.
l New three-axis pneumatic cylinder flexible flat scraper, ensuring cleaner glue removal without damaging the board.
Technical data:
| Lifting | CNC lift |
| Total power | About 29.5kw |
| Overall Dimensions | About 10100x1000x2000mm |
| Feed Rate |
Gluing:14-18-23-26m/min, Laser:≤23m/min(When the thickness of the workpiece is 18mm, the maximum feed speed is about 23m/min.) |
| Edge Band Thickness | gluing:0.4-3mm,laser:1-3mm |
| Board Thickness | gluing:10-60mm,laser:10-25mm |
| Board Length | Corner rounding off≥120mm; Corner rounding on≥300mm |
| Board Width | 40mm |
| Operating Pressure | 0.6Mpa |
Heavy Duty Steel Pressure Beam
Siemens Intelligent Control System
Automatic side press for narrow boards
Heating unit
Gluing:Two-colour PUR clean free glue pot
Double rows type PUR hot melt pump glue machine
Patented laser system
Pressing unit
Two rails three motors fast end-cutting
Trimming unit for narrow edge+Fine trimming
One-piece four-tool high-speed corner rounding
Two sets of scraping
Off-cut device + flexible flat scraping + cleaning agent device
Two sets of buffing
Hard Gear Conveyor Geared Motors
